NS6A5.0AT3G
600 Watt Peak Power Zener
Transient Voltage
Suppressors
Unidirectional
The NS6A5.0AT3G is designed to protect voltage sensitive
components from high voltage, high energy transients. This device
has excellent clamping capability, high surge capability, low zener
impedance and fast response time. The NS6A5.0AT3G is ideally
suited for use in computer hard disk drives, communication systems,
automotive, numerical controls, process controls, medical
equipment, business machines, power supplies and many other
industrial/consumer applications.
http://onsemi.com
PLASTIC SURFACE MOUNT
ZENER OVERVOLTAGE
TRANSIENT SUPPRESSORS
Specification Features:
Cathode
Anode
?
?
?
?
?
?
?
Peak Reverse Working Voltage of 5 V
Peak Pulse Power of 600 W (10 x 1000 m sec)
ESD Rating of Class 3 (>16 kV) per Human Body Model
ESD Rating of Class 4 (>8 kV) IEC 61000 ? 4 ? 2
Fast Response Time
Low Profile Package
This is a Pb ? Free Device
SMA
CASE 403D
PLASTIC
MARKING DIAGRAM
6QE
Mechanical Characteristics:
AYWW G
CASE: Void-free, transfer-molded, thermosetting plastic
FINISH: All external surfaces are corrosion resistant and leads are
readily solderable
MAXIMUM CASE TEMPERATURE FOR SOLDERING PURPOSES:
260 ° C for 10 Seconds
LEADS: Modified L ? Bend providing more contact area to bond pads
POLARITY: Cathode indicated by polarity band
6QE
A
Y
WW
G
= Specific Device Code
= Assembly Location
= Year
= Work Week
= Pb ? Free Package
MOUNTING POSITION: Any
ORDERING INFORMATION
Device
NS6A5.0AT3G
Package
SMA
Shipping ?
5000/Tape & Reel
(Pb ? Free)
?For information on tape and reel specifications,
including part orientation and tape sizes, please
refer to our Tape and Reel Packaging Specifications
Brochure, BRD8011/D.
? Semiconductor Components Industries, LLC, 2008
November, 2008 ? Rev. 1
1
Publication Order Number:
NS6A5.0A/D
